npc_eli
Jump to navigation
Jump to search
Note:Some keyvalues, spawnflags, effect flags, inputs, or outputs might not affect an NPC, based on the functionality and coding of the NPC.
 Class hierarchy
|
|---|
| CNPC_Eli |
| npc_eli.cpp
|
npc_eli is a model entity available in
Half-Life 2 series.
Eli Vance
Dr. Eli Vance, Earth's last great hope, single-handedly fighting off both an evil alien invasion, as well as trying to stop that idiot lab assistant from putting the moves on his daughter.
Note:Some keyvalues, spawnflags, effect flags, inputs, or outputs might not affect an NPC, based on the functionality and coding of the NPC.Keyvalues
- Name (targetname) <string>[ Edit ]
- The name that other entities refer to this entity by, via Inputs/Outputs or other keyvalues (e.g.
parentnameortarget).
Also displayed in Hammer's 2D views and Entity Report.See also: Generic Keyvalues, Inputs and Outputs available to all entities
- World Model (model) <model path>[ Edit ]
- In-game 3D representation of the entity to display. This is the path to a MDL relative to the game's root directory. (128 character limit)
- If no model specified this defaults to
models/eli.mdl
TalkNPC:
- Un-Use Sentence (UnUseSentence) <string>
- Sentence spoken NPC gets used again
- Don't Use Speech Semaphore (DontUseSpeechSemaphore) <boolean>
- Friendly NPCs are not allowed to speak if another friendly NPC is speaking. In some cases, we don't want speaking NPCs to prevent other NPCs from speaking (for instance, if there is a friendly NPC speaking for a long time on a monitor). To make this NPC not prevent other NPCs from talking, make it not grab the semaphore when it speaks.
|
CBaseCombatCharacter:
CAI_BaseNPC:
DamageFilter:
|
Outputs
|
Inputs
TalkNPC:
- SpeakResponseConcept <string> (in all games since
) - Speak the specified response concept immediately.
BaseNPC inputs
CAI_BaseNPC:
- ActivateSpeedModifier !FGD
- DisableSpeedModifier !FGD
- Break
- Smash into pieces. If this is not possible, disappear.
- BecomeRagdoll (in all games since
) - Remove itself and instantly become a ragdoll with zero force (just go limp). OnDeath, etc. outputs will NOT be fired.
- ForceInteractionWithNPC <string> <string> (in all games since )
- Force the NPC to use a dynamic interaction with another NPC. Syntax is <targetname> <dynamic interaction>.
- ForgetEntity <targetname>
- Clears out the NPC's knowledge of a named entity.
- UpdateEnemyMemory (in all games since )
- Update (or create) this NPC's memory of of the given entity.
- GagEnable
- GagDisable
- Gagged NPCs won't speak (or moan, caw, etc.) unless made to be a choreographed scene.
- HolsterWeapon (in all games since )
- UnholsterWeapon (in all games since )
- Force the NPC to holster or unholster their weapon. Ignored if the NPC is scripting or if the NPC doesn't use weapons.
- HolsterAndDestroyWeapon (in all games since )
- Same as
HolsterWeapon, except the weapon is destroyed once it has been concealed.
- IgnoreDangerSounds <float>
- Ignore danger sounds for the specified number of seconds.
- InsideTransition !FGD
- OutsideTransition !FGD
- SetBodyGroup <integer>
- HACK: Sets this NPC's body group (from 0–n).
- SetEnemyFilter <string>
- SetHealth <integer>
- Set the NPC's health.
- SetRelationship <string|targetname or classname> <string|disposition> <int|rank>
- Changes whether this NPC likes or dislikes certain others. Used like the ai_relationship entity, with this NPC as the subject.
- Values for
dispositionare:D_HT: HateD_FR: FearD_LI: LikeD_NU: Neutral
- SetSquad <string>
- Change the name of this NPC's squad. Leaving the parameter blank will remove the NPC from any existing squad.
- StartScripting
- StopScripting
- Enter/exit scripting state, where NPCs ignore a variety of stimulus that would make them break out of their scripts. They ignore danger sounds, ignore +Use, don't idle speak or respond to other NPCs' idle speech, and so on.
- Wake
- Wakes up the NPC if it is sleeping.
CBaseCombatCharacter:
- KilledNPC !FGD
- Tells the entity it killed something. Despite the name, this can include a player. This input will be automatically sent by the victim when they die.
- physdamagescale <float>
- Scales damage energy when this character is hit by a physics object. With a value of 0 the NPC will take no damage from physics.
DamageFilter:
Flags
BaseNPC flags
- Wait Till Seen : [1]
- Prevents this NPC from seeing (or being seen) until it enters a player's viewcone.
- Gag : [2]
- Won't make IDLE sounds until it's angry.
- Fall to ground (unchecked means teleport to ground) : [4]
- Drop Healthkit : [8]
- Causes this NPC to drop an item_healthvial upon dying.
- Efficient : [16]
- Don't acquire enemies or avoid obstacles
- Wait For Script : [128]
- Forces this NPC to "wait" in an idle state until it finishes playing a scripted_sequence.
- Long Visibility/Shoot : [256]
- By default, increases a NPC's sight range to
6,000units and allows it to attack from anywhere within that distance.
- Fade Corpse : [512]
- Think outside PVS : [1024]
- Allows this NPC to run its regular AI outside of any player's PVS.
- Template NPC : [2048]
- Marks this NPC as a template for entities like npc_template_maker. The NPC will not spawn on its own. This is not needed for point_template.
- Do Alternate collision for this NPC (player avoidance) : [4096]Note:This flag is disabled in episodic for player companions, because the
StartScriptinginput does this.
- Don't drop weapons : [8192]
- Ignore player push : [16384] (in all games since
) - Entity won't give way to player.
